Coiled H65 Copper Wire
Henan Gnee New Material Co., Ltd. is one of the most professional manufacturers and suppliers of coiled h65 copper wire in China, specialized in providing high quality copper products with competitive price. Welcome to buy discount coiled h65 copper wire for sale here from our factory. Customized orders are welcome.
What is Coiled H65 Copper Wire?
Our Coiled H65 Copper Wire (Yellow Brass Wire) is a cornerstone material for modern manufacturing. Often referred to as 65/35 brass due to its copper and zinc ratio, H65 offers a unique combination of high elongation and respectable tensile strength.
The "Coiled" format is specifically designed for industrial-scale operations. Unlike small spools, our large-capacity coils are engineered for seamless integration with heavy-duty machinery used in fastener production, mesh weaving, and electrical component forming. Each coil undergoes strict tension and alignment checks to guarantee a consistent payoff speed, preventing wire breakage and optimizing your factory's output efficiency.
H65 solid copper wire has the following advantages:
1. good electrical conductivity: copper is a metal material with high electrical conductivity, which can ensure good electrical conductivity.
2. Strong corrosion resistance: zinc plays a protective role for copper in the alloy, which can effectively prevent copper from being oxidized, thus prolonging the service life of brass wire.
3. Convenient processing: H65 brass wire has good ductility and weldability, which is convenient for processing and connection.
4. Wide range of applications: H65 brass wire is widely used in electronics, electrical appliances, communications, automobiles, machinery and other fields.
Professional H65 Copper Wire Supplier--GNEE
Chemical Composition
| Element | Content (%) |
| Copper (Cu) | 63.5% - 68.0% |
| Zinc (Zn) | Remainder |
| Lead (Pb) | ≤ 0.03% |
| Iron (Fe) | ≤ 0.10% |
| Total Impurities | < 0.3% |
Mechanical Properties
| Property | Specification |
| Tensile Strength | 340 - 450 MPa (Customizable) |
| Elongation at Break | ≥ 25% - 45% |
| Hardness (HV) | 80 - 120 HV |
| Elastic Modulus | 105 GPa |
Physical Property
| Physical Property | Specification |
|---|---|
| Density (g/cm³) | 8.47 |
| Electrical Conductivity (%IACS) | ≥ 24 |
| Electrical Conductivity (MS/m) | 13.92 |
| Thermal Conductivity (W/(m·K)) | 111.6 |
| Coefficient of Thermal Expansion (10^-6/K) | 20.1 |
| Elastic Modulus (GPa) | 105 |
| Specific Heat Capacity (J/(g·K)) | 0.377 |
| Poisson's Ratio | 0.34 |
Grade Comparison Table
| Feature | H65 (C27000) | H70 (C26000) | H62 (C28000) |
| Copper Content | ~65% | ~70% | ~62% |
| Formability | High | Highest | Moderate |
| Strength | Moderate-High | Moderate | High |
| Typical Format | Industrial Coil/Spool | Thin Wire/Deep Drawing | Rods/Plates |
When choosing H65 metal copper wire, you need to consider the following aspects:
1. Appearance: high-quality H65 brass wire has a smooth surface, without oil, oxidation, discoloration and other phenomena.
2. Material: choose H65 brass wire with appropriate ratio of copper-zinc alloy, too high copper content will make the material hard and unfavorable for processing, while too low copper content will make the material too soft and insufficient strength and hardness.
3. Specification: Choose the appropriate wire diameter and specification according to the actual need.
4. Performance: High-quality H65 brass wire has good electrical conductivity and corrosion resistance, and can meet the requirements for use in various harsh environments.
Large-scale factory production of H65 solid copper wire
Why choose our H65 grounded copper wire
We are a professional copper products manufacturer and exporter specializing in copper tubes, rods, wires, plates, and strips. Our factory is equipped with advanced production lines, including continuous casting and upcasting machines, cold rolling mills, drawing machines, annealing furnaces, and precision cutting equipment, enabling us to deliver products with consistent quality and tight tolerances. Every batch undergoes rigorous testing-including chemical composition analysis, mechanical property testing, dimensional inspection, electrical conductivity testing, and eddy current/ultrasonic defect detection-and we support third-party inspection (SGS, BV, etc.) to ensure full compliance with ASTM, EN, JIS, and GB standards. With competitive pricing, flexible MOQs, and professional export service, we look forward to building long-term partnerships and supplying copper products that meet your exact requirements.
