Copper Nickel Pipes

Gnee Steel (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of copper nickel pipes in China, also supports customized service. Welcome to buy discount copper nickel pipes for sale here from our factory. Quality products and reasonable price are available.

The main components of copper-nickel tubes include copper and nickel, and sometimes other alloying elements. For example, C71500 copper-nickel alloy is mainly composed of copper and nickel, with a copper content between 65.0% and 70.0%, and a nickel content between 29.0% and 33.0%. It may also contain small amounts of iron, manganese and other elements. In addition, the common ratio of B10 copper-nickel alloy is 90% copper and 10% nickel. 2.

The composition of copper-nickel tubes varies according to specific applications and performance requirements. For example, C71500 copper-nickel alloy is suitable for application scenarios that require high strength and high corrosion resistance. 1. B10 copper-nickel alloy is often used in applications that require good corrosion resistance and medium strength. 2. The composition of these alloys can be adjusted to meet different engineering needs, such as improving strength, corrosion resistance or conductivity.

The welding process of copper-nickel welded pipe mainly includes several steps such as pre-welding preparation, welding process and post-welding treatment. First of all, the copper-nickel pipe port needs to be cleaned before welding to remove oil, oxide layer and other impurities on the surface to ensure the welding quality. Generally, chemical cleaning or mechanical grinding is used, and it needs to be wiped with a clean cloth after cleaning to prevent re-contamination.

The welding process usually uses argon arc welding (TIG welding) because of its high welding quality and suitability for thin-walled materials. When welding, suitable welding materials should be selected, and welding rods with the same or similar composition as the welded materials are usually used to avoid the generation of brittle phases in the welding area. During the welding process, it is necessary to control the welding current and welding speed, maintain a stable welding pool, and avoid welding defects such as pores and cracks.

Post-welding treatment is equally important. After welding, the welding part needs to be cleaned, usually by pickling or sandblasting, to remove the welding slag and oxides in the welding process to restore the corrosion resistance of the copper-nickel material. In addition, heat treatment may be required in some cases to eliminate the internal stress generated during welding and improve the mechanical properties of the welded joint.

In short, the welding process of copper-nickel welded pipes has strict requirements and needs to be reasonably designed and implemented according to the specific application and material properties to ensure the long-term stability and reliability of the welded joints.
