C14500 Tellurium Copper
Henan Gnee New Material Co., Ltd. is one of the most professional manufacturers and suppliers of c14500 tellurium copper in China, specialized in providing high quality copper products with competitive price. Welcome to buy discount c14500 tellurium copper for sale here from our factory. Customized orders are welcome.
C14500, or tellurium copper, has similar mechanical properties to unalloyed, pure copper but with a higher machinability. The cutting properties of C14500 are enhanced significantly by creating a copper alloy with the addition of tellurium. Tellurium copper is also known for its high electrical conductivity characteristic.
| CDA | ASTM | SAE | AMS | Federal | Military | Other |
|---|---|---|---|---|---|---|
| C14500 | B124 B124M B301 B301M |
J461 J463 |
Tellurium-Bearing (PTE) |
| Cu%1,2 | P% | Te% | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
Chemical Composition according to ASTM B301/B301M-13(2020)1Includes silver 2Includes tellurium and phosphorus
Note: Includes oxygen-free or deoxidized grades with deoxidizers (such as phosphorus, boron, lithium, or other) in an amount agreed upon. Unless otherwise noted, single values represent maximums.
|
|||||||||||
| 99.90 min |
0.004- 0.012 |
0.40- 0.70 |
|||||||||
C14500
H04 Hard
SIZE RANGE: 1/16″ DIAMETER ROD (ROUND ONLY) TO 1/4″ INCLUSIVE
| Tensile Strength, min | Yield Strength, at 0.5% Extension Under Load, min | Elongation, 4x Diameter or Specimen Thickness, min | Brinell Hardness (500 kg load) | Remarks | ||
|---|---|---|---|---|---|---|
| Ksi | MPa | Ksi | MPa | % | typical BHN | |
| 48 | 330 | 40 | 275 | 4 | 81 | |
SIZE RANGE: OVER 1/4″ DIAMETER ROD (ROUND ONLY) TO 1 1/4″ INCLUSIVE
| Tensile Strength, min | Yield Strength, at 0.5% Extension Under Load, min | Elongation, 4x Diameter or Specimen Thickness, min | Brinell Hardness (500 kg load) | Remarks | ||
|---|---|---|---|---|---|---|
| Ksi | MPa | Ksi | MPa | % | typical BHN | |
| 44 | 305 | 38 | 260 | 8 | 81 | |
