C12000 High-pressure Oil/gas Pipes
Gnee Steel (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of c12000 high-pressure oil/gas pipes in China, also supports customized service. Welcome to buy discount c12000 high-pressure oil/gas pipes for sale here from our factory. Quality products and reasonable price are available.
C12000 (TP1) High-Pressure Oil & Gas Pipes
C12000 seamless copper tubes are an excellent choice for demanding high-pressure oil and gas transmission applications due to their unique combination of material properties, which ensure safety, durability, and performance in critical systems.
Why is C12000 suitable for high-pressure oil/gas lines?
| Property | Benefit for Oil/Gas Applications |
|---|---|
| High Strength & Pressure Resistance | Withstands elevated operating pressures in hydraulic, pneumatic, and fuel systems without deformation or bursting. |
| Superior Fatigue Resistance | Maintains integrity under cyclic pressure loading and vibration, common in industrial and mobile equipment. |
| Excellent Corrosion Resistance | Resists degradation from hydrocarbons, moisture, and certain aggressive media, extending service life. |
| Good Thermal Conductivity | Helps dissipate heat generated by compression or friction in high-flow systems. |
| Non-Sparking Characteristic | Enhances safety in flammable gas or volatile liquid environments (compared to steel). |
| Ease of Fabrication & Joining | Can be bent, flared, and brazed/soldered reliably to create complex, leak-free piping assemblies. |
C12000 (TP1) Copper - Typical Chemical, Mechanical & Physical Properties
| Property Category | Specification / Typical Value | Standard / Condition | Notes |
|---|---|---|---|
| Chemical Composition | ASTM B | ||
| Copper (Cu) | ≥ 99.90% | Minimum value. | |
| Phosphorus (P) | 0.004 – 0.012% | Defines TP1 (Low residual P). | |
| Mechanical Properties | |||
| Tensile Strength | Annealed (O60): ≥ 195 MPa Hard Drawn (H80): 345 – 415 MPa |
ASTM B88 / B280 | Varies with temper and size. |
| Yield Strength (0.5% Ext.) | Annealed: ~ 45 MPa Hard Drawn: ≥ 310 MPa |
ASTM B88 / B280 | |
| Elongation (% in 50 mm) | Annealed: ≥ 40% Hard Drawn: ≥ 10% |
ASTM B88 / B280 | |
| Hardness (Rockwell F) | Annealed: ~ 45 HRF Hard Drawn: ~ 85 HRF |
Approximate values. | |
| Physical Properties | |||
| Density | 8.94 g/cm³ (0.323 lb/in³) | at 20°C | |
| Melting Point | ~1083°C (1981°F) | ||
| Thermal Conductivity | ~ 391 W/(m·K) | at 20°C | Approx. 100% IACS. Slightly higher than C12200. |
| Electrical Conductivity | ~ 101% IACS | at 20°C | Reference: 100% IACS = 58.0 MS/m. |
| Coefficient of Thermal Expansion | 17.0 x 10⁻⁶ /K | 20–300°C | |
| Key Application Features | |||
| Weldability/Brazability | Excellent | Phosphorus acts as a deoxidizer. | |
| Corrosion Resistance | Excellent (Atmospheric, Water) | Good resistance to stress corrosion cracking. | |
| Formability | Excellent (especially in annealed temper) | Suitable for bending, flaring, expanding. |
C12000 (TP1) Applications
Hydraulic Lines: For industrial machinery, presses, and mobile equipment.
Fuel & Oil Transfer Lines: In compressors, generators, and processing systems.
Instrumentation & Control Tubing: For pneumatic controls and sensor connections in harsh environments.
High-Purity Gas Lines: Where copper's cleanliness and non-contaminating properties are valued.
TP1 Standards & Specifications
Primary Standard: ASTM B75 – Standard Specification for Seamless Copper Tube (general industrial use).
Dimensional Standards: Often supplied to ASTM B88 (water tube) dimensional schedules (Types K, L, M) for compatibility with fittings.
Temper: Typically supplied in hard (H80) or half-hard (H55) temper to maximize pressure rating and mechanical strength.
Testing: Can include hydrostatic pressure testing, eddy current testing, and full material certification per customer requirements.
C12000 Comparison with Alternatives
| Material | vs. C12000 Copper |
|---|---|
| Stainless Steel | Copper is easier to bend and join, non-sparking, and more thermally conductive, but has lower ultimate tensile strength. |
| TP2/C12200 Copper | C12000 offers marginally higher strength and conductivity, beneficial for performance-critical or thermally sensitive high-pressure systems. |
| Carbon Steel | Copper is corrosion-resistant without coating, lighter, but more expensive per unit strength. |
Selection Considerations
Pressure & Temperature Ratings: Must be calculated based on tube OD, wall thickness (schedule), and temper. Hard temper C12000 provides the highest pressure capacity.
Media Compatibility: Confirm compatibility with specific oils, gases, or additives (e.g., certain synthetic lubricants or sour gases may require evaluation).
Jointing Method: Brazed/soldered joints are common; ensure proper procedure to maintain strength. Flared or compression fittings are also used.
Cost vs. Lifecycle Value: While initial cost is higher than some alternatives, copper's durability, low maintenance, and safety benefits often justify the investment.
