Brass Thread Valve
Henan Gnee New Material Co., Ltd. is one of the most professional manufacturers and suppliers of brass thread valve in China, specialized in providing high quality copper products with competitive price. Welcome to buy discount brass thread valve for sale here from our factory. Customized orders are welcome.
Actuator
|
Item No. |
HV04CKA |
HV04CKB |
HV04AKA |
HV04AKB |
|
Voltage Supply |
AC220V±10%, 50/60Hz |
AC24V±10%, 50/60Hz |
||
|
Power Consumption |
6.5W |
|||
|
Torque |
4Nm |
|||
|
Control Mode |
3 wires-single-control |
3 wires dual control |
3 wires single control |
3 wires dual control |
|
Run time |
Open<15s Close<15s |
|||
|
Lead Supply |
3 Core(Brown, Blue, Black) |
|||
|
Environment Temperature |
0℃(32℉)-50℃(122℉) non condensing |
|||
Valve Body
|
Item No. |
AN20P215 |
AN20P315 |
AN20P220 |
AN20P320 |
AN20P225 |
AN20P325 |
AN20P232 |
|
Action Type |
2-Way |
3-Way |
2-Way |
3-Way |
2-Way |
3-Way |
2-Way |
|
Rate Pressure |
1.6MPa |
||||||
|
Services Medium |
Chilled and or Hot Water, Up to 50% Glycol |
||||||
|
Environment Temperature |
0℃(32℉)-50℃(122℉) non condensing |
||||||
|
Fluid Temperature |
0℃(32℉)-94℃(203℉) |
||||||
|
Material |
Valve Body: Forged Brass Valve Stem: brass Valve Core: SS(304) Valve Seal: EPDM |
||||||
|
DN Size |
DN15 |
DN15 |
DN20 |
DN20 |
DN25 |
DN25 |
DN32 |
|
End Connection |
BSPP / NPT Internal Threaded |
||||||
|
Size(Inch) |
1/2" |
1/2" |
3/4" |
3/4" |
1" |
1" |
1-1/4" |
|
Kv (Cv) Value |
4.0(4.7) |
4.0(4.7) |
7.0(8.2) |
7.0(8.2) |
12.0(14.0) |
12.0(14.0) |
19.0 (22.0) |
