TP2 Thin Wires
Gnee Steel (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of tp2 thin wires in China, also supports customized service. Welcome to buy discount tp2 thin wires for sale here from our factory. Quality products and reasonable price are available.
Features of TP2 fine copper wire:
Excellent electrical conductivity: TP2 copper violet has very good electrical conductivity, its conductivity is about 90-98% IACS (International Acoustic Conductivity Unit), which is suitable for the manufacture of parts that require electrical conductivity.
High mechanical properties: TP2 copper violet wire has relatively good hardness and strength, with good plasticity and toughness, suitable for manufacturing higher strength parts.
Excellent corrosion resistance: TP2 bare copper wire has good corrosion resistance and can be used in different corrosive environments.
Latest technology to produce TP2 fine copper wire
Chemical Composition of TP2 Copper Wire
| Element | Content Range (wt%) |
|---|---|
| Copper (Cu) | ≥ 99.85 |
| Phosphorus (P) | 0.013 - 0.050 |
| Silver (Ag) | Trace amounts |
| Tin (Sn) | ≤ 0.01 |
| Lead (Pb) | ≤ 0.005 |
| Nickel (Ni) | ≤ 0.01 |
| Iron (Fe) | ≤ 0.05 |
| Antimony (Sb) | ≤ 0.002 |
| Sulfur (S) | ≤ 0.005 |
| Bismuth (Bi) | ≤ 0.002 |
| Oxygen (O) | ≤ 0.01 |
| Impurities | ≤ 0.15 |
Physical Properties of TP2 Copper Wire
| Property | Specification |
|---|---|
| Density (g/cm³) | 8.94 |
| Tensile Strength (MPa) | 215 - 271 |
| Elongation (%) | ≥ 25 |
| Hardness (HV) | 55 - 100 |
| Electrical Conductivity | High |
| Thermal Conductivity | High |
| Thermal Expansion Coefficient (10^-6/K) | Approx. 17.6 |
TP2 pure copper wire has good electrical conductivity, mechanical properties, corrosion resistance, processing performance and welding performance, so it is widely used in electronic devices, communication cables, printed circuit boards, chemical equipment, heat exchangers, boilers and other fields.
Supply of TP2 Bare Copper Wire with Excellent Performance
Why choose our TP2 grounded copper wire
GNEE was established in 2008 with 16 years of manufacturing and sales experience. With many years of production experience and independent production factories, we can provide you with customized products. Meanwhile, we cooperate with many famous factories, which can provide you with large quantities of high quality metal. We have up to 200 employees and will continue to grow in the future. All of them are committed to providing you with better products and services. We are committed to providing you with the best products and services, and we will provide you with more favorable pricing and safe and fast transportation solutions.GENN is trustworthy. We look forward to working with you.
